McIntosh MA252
Hybrid Integrated Amplifier
Interest Free Credit Available
£4,995.00

In-Store Only

This item is only available for purchase in-store, please contact your local store for more information.

McIntosh MA252 Hybrid Integrated Amplifier

2-Channel Hybrid Integrated Amplifier

  • Includes MCIntosh Hybrid Drive™ technology that uses the best of vacuum tubes and solid state to produce the best sound performance
  • Vacuum tube preamplifier and solid state power amplifier
  • 100 Watts into 8 Ohms
  • 160 Watts into 4 Ohms

The MA252 Integrated Amplifier is the first hybrid integrated amplifier from McIntosh. Taking retro design cues from the legendary McIntosh MC275 Vacuum Tube Amplifier, the MA252 combines the best of vacuum tube and solid state circuit design to create an amplifier that’s both visually and sonically stunning.

McIntosh MA252 Hybrid Integrated Amplifier

All analog design

This beautifully crafted integrated amplifier includes McIntosh Hybrid Drive™ technology that uses the best of vacuum tubes and solid state to produce the best sound performance. The preamplifier stage uses two 12AX7a and two 12AT7 vacuum tubes housed inside stylish protective cages; the output stage is a direct coupled solid state amplifier that delivers 100 Watts per channel into 8 Ohm speakers or 160 Watts per channel into 4 Ohm speakers. An all analog design, it comes with 2 unbalanced, 1 balanced and 1 Moving Magnet phono input for turntables. All 4 inputs can be given user-friendly names in order to simplify user control. Bass and treble tone controls help fine tune your music to your personal preferences. A full range subwoofer output is included for use with a powered subwoofer to further enhance low frequencies.

McIntosh MA252 Hybrid Integrated Amplifier

Monogrammed Heatsinks™

The MA252 features McIntosh Monogrammed Heatsinks™ which are connected to advanced high current output transistors. These transistors eliminate the typical amplifier warm-up time so that the MA252 is in peak operating condition from the moment it’s turned on. A powerful control microprocessor is used for smooth system operation, along with some of the latest audio-grade circuit components that deliver the best possible sound.

Power Guard

Thanks to its solid state output, the MA252 is McIntosh's first product containing vacuum tubes to include McIntosh patented Power Guard® technology. Power Guard monitors the output signal for signs of over driving and makes real time micro adjustments to the input signal to prevent harsh sounding clipping that could potentially damage your speakers. If Power Guard is activated, the 2 vacuum tubes connected to the affected audio channel(s) will flash an amber color; they will return to their normal green color when the clipping has stopped.

McIntosh MA252 Hybrid Integrated Amplifier

Power Guard

Other McIntosh technologies found in the MA252 include Sentry Monitor™, High Drive headphone amplifier and gold-plated speaker binding posts. Input selection, bass, treble, tone bypass, balance and input offset levels can be adjusted using the front panel knobs or the included remote control; all settings and input selection will be shown on the OLED display. The entire unit sits atop a beautiful polished stainless steel chassis with a classic McIntosh-styled die cast aluminum name badge attached to each side. Contact your local dealer to learn more.

McIntosh MA252 Hybrid Integrated Amplifier

ELECTRONIC SPECIFICATIONS

    Power Output per Channel
    100 Watts into 8 Ohms
    160 Watts into 4 Ohms
    Number of Channels
    2
    Speaker Impedance
    4 or 8 Ohms
    Rated Power Band
    20Hz to 20kHz
    Total Harmonic Distortion
    0.03%
    Dynamic Headroom
    1.8dB
    Frequency Response +0,-0.5dB
    20Hz to 20kHz
    Frequency Response, +0, -3dB
    10Hz to 100kHz
    Sensitivity Phono (Moving Coil)
    N/A
    Sensitivity Phono (Moving Magnet)
    3.0mV
    Sensitivity High Level (Balanced / Unbalanced)
    0.6V/0.3V
    Sensitivity (Power Amp input)
    N/A
    Signal To Noise Ratio (Moving Coil)
    N/A
    Signal To Noise Ratio (Moving Magnet)
    80dB
    Signal To Noise Ratio (High Level)
    97dB
    Signal To Noise Ratio (Power Amp input)
    N/A
    Input Impedance (Balanced / Unbalanced)
    20K/20K
    Damping Factor
    8 Ohms: >200
    4 Ohms: >100
    Maximum Output (Balanced / Unbalanced)
    8V Unbalanced

CONNECTIVITY

    Balanced Input
    1
    Unbalanced Input
    2
    Phono Input Moving Coil
    0
    Phono Input Moving Magnet
    1 (fixed loading)
    Upgradeable Digital Audio Module
    No
    Digital Coaxial Input
    0
    Digital Optical Input
    0
    Digital MCT Input
    0
    Digital USB Input
    0
    HDMI (ARC) Input
    0
    Balanced Variable Output
    0
    Unbalanced Fixed Output
    0
    Unbalanced Variable Output
    0
    Headphone Output
    1/4" High Drive
    Subwoofer Output
    1 (mono)
    AM/FM Tuner option
    No
    Home Theater PassThru
    No
    Unbalanced Analog Connector Type
    Standard
    Speaker Binding Post Type
    Standard
    Service Port
    0

DIGITAL AUDIO SPECIFICATIONS

    Digital-to-Analog Converter (DAC) Type
    N/A
    Digital Coaxial Input Sample Rate
    N/A
    Digital Optical Input Sample Rate
    N/A
    Digital MCT Input Sample Rate
    N/A
    Digital USB Input Sample Rate
    N/A

CONTROL

    Tone Controls
    Bass and Treble
    Tone Bypass and Input Assign
    Yes
    RS232 Control Input
    No
    Power Control Output
    1
    Rear Panel Data Port
    1
    Rear Panel IR Sensor Input
    No
    Input Level Match
    Yes

GENERAL SPECIFICATIONS

    Vacuum Tube or Solid State
    Preamplifier: Vacuum Tube
    Power Amplifier: Solid State
    Output Type
    Direct Coupled
    Output Meters
    No
    Dual Layer Chassis
    Yes
    Chassis Finish
    Polished stainless steel
    McIntosh Monogrammed Heatsinks™
    Yes
    Power Requirement
    120V 50/60Hz, 3.7A
    Standby Power Requirement
    <0.5 Watts

WEIGHTS & DIMENSIONS

    Unit Dimensions (W x H x D)
    12" (30.5cm) x 7-5/8" (19.4cm) x 16-1/2" (41.9cm)
    Unit Weight
    28 lbs (12.7 kg)
    Shipping Weight
    37 lbs (16.8 kg)
User Manual
MA252 User Manual
